Boolean Algebra proof?


Coder

Recommended Posts

Hello all,
This is my first post here as I am new here.

My question is in this proof listed below in the image. I can't understand a line how is this possible in Boolean Algebra.
Any help will be appreciated. :)


Link to comment
Share on other sites

Truth table:



X Y | X+X.Y

|

0 0 | 0

0 1 | 0

1 0 | 1

1 1 | 1



So X+X.Y = X for every case.



Intuitively, if X is true then the result is true (the second term doesn't matter). if X is false, then the second term is false too.


The line you questioned, specifically, is 1+Y = 1. But that's just the definition of logical OR - if either term is true then the OR of the terms is true.

Link to comment
Share on other sites

Truth table:



X Y | X+X.Y

|

0 0 | 0

0 1 | 0

1 0 | 1

1 1 | 1



So X+X.Y = X for every case.



Intuitively, if X is true then the result is true (the second term doesn't matter). if X is false, then the second term is false too.

The line you questioned, specifically, is 1+Y = 1. But that's just the definition of logical OR - if either term is true then the OR of the terms is true.

Now my doubt is cleared. Thanks for helping.

Link to comment
Share on other sites
